1500VDC ES-RYJ-125 4mm2 6mm2 Energy storage Cable
▲Easy stripping and cutting
▲Good flexibility
▲Good low temperature resistant
▲Good high temperature resistant
▲Acid and alkaline resistant
▲High flamen retardant
Product Information:
Tinned or bare, stranded or solid copper
CQC1143、PPP58049A
Name
High temperature ES-H15Z-F resistant cable
Conductor
Insulation
Lead free XLPO, passed RoHS
Rated voltage
DC 1500V
Rated temperature
125°C
Reference Standard
Flame test
IEC60332-1
| Cable Name |
Cross Section (mm2) |
Construction (No./mm) |
Conductor O.D. (mm) |
Insulation O.D. (mm) |
Conductor Resistance Max (?/km) |
|
ES-RYJ-125/ ES-H09Z-F |
4 | 56/0.30 | 2.59 | 4.25 | 5.09 |
| 6 | 84/0.30 | 3.17 | 4.85 | 3.39 | |
| 10 | 78/0.40 | 4.08 | 5.90 | 1.95 | |
| 16 | 126/0.40 | 5.59 | 7.90 | 1.24 | |
| 25 | 196/0.40 | 6.95 | 9.70 | 0.795 | |
| 35 | 276/0.40 | 8.30 | 11.00 | 0.565 | |
| 50 | 396/0.40 | 9.90 | 13.00 | 0.393 | |
| 70 | 553/0.40 | 11.70 | 14.80 | 0.277 | |
| 95 | 760/0.40 | 13.87 | 17.00 | 0.210 | |
| 120 | 950/0.50 | 15.50 | 18.60 | 0.164 | |
| 150 | 1178/0.40 | 17.26 | 20.90 | 0.132 | |
| 185 | 1463/0.40 | 19.24 | 23.20 | 0.108 | |
| 240 | 1911/0.40 | 23.40 | 27.60 | 0.0187 |
