Oil resistant electronic cable UL1284 with PVC insulation wire
▲Solid or stranded ,tinned or bare copper conductor 8~500kcmil
▲Lead free PVC insulation ,Oil Resistant (Optional), comply with ROHS environmental standard
▲Uniform insulation thickness to ensure easy stripping and cutting
Product Information:
Preferentially tinned copper stranded ，or bare copper stranded or solid conductor.
8AWG~500kcmil.
UL758，UL1581
Conductor
Insulation
Lead free PVC, Oil Resistant (Optional), passed RoHS
Rated voltage
600V
Rated temperature
105°C
Reference Standard
Flame Test
UL VW-1 & CSA FT 1
| Cable Name |
Cross Section (AWG) |
Construction (No./mm) |
Conductor O.D. (mm) |
Insulation O.D. (mm) |
Conductor Resistance Max (?/km) |
| UL style 1284 | 8 | 168/0.254 | 4.20 | 7.30 | 2.35 |
| 7 | 210/0.254 | 4.70 | 7.80 | 1.87 | |
| 6 | 266/0.254 | 5.30 | 8.40 | 1.48 | |
| 5 | 329/0.254 | 5.80 | 9.00 | 1.17 | |
| 4 | 420/0.254 | 6.60 | 9.70 | 0.928 | |
| 3 | 532/0.254 | 7.50 | 10.50 | 0.744 | |
| 2 | 665/0.254 | 8.40 | 11.50 | 0.590 | |
|
1 |
836/0.254 | 9.40 | 13.5 | 0.467 | |
| 1/0 | 1045/0.254 | 10.50 | 14.6 | 0.370 | |
|
2/0 |
1330/0.254 | 11.90 | 16.0 | 0.297 | |
|
3/0 |
1672/0.254 | 13.00 | 17.5 | 0.236 | |
| 4/0 | 2109/0.254 | 14.70 | 19.1 | 0.187 |
