UL listed hook up wire UL1015 12awg 14awg 16awg 18awg electric wire of solid or stranded copper conductor
UL style 1015 lead wire is a general-purpose electronic hook up wire, used in the internal wiring of appliances and electronic equipment, it can resistant to water, oil, acid, solvent and fungus .
Product Information:
Preferentially tinned copper stranded ，or bare copper stranded or single conductor. 28AWG~500kcmil.
UL758，UL1581
Conductor
Insulation
Lead free PVC, passed RoHS
Rated voltage
600Vac or 750Vdc
Rated temperature
80℃ or 90℃ or 105℃
Reference Standard
Flame Test
UL VW-1 & CSA FT 1
| Cable Name |
Cross Section (mm2) |
Construction (No./mm) |
Conductor O.D. (mm) |
Insulation O.D. (mm) |
Conductor Resistance Max (?/km) |
|
UL style 1015 |
24 | 11/0.16 | 0.61 | 2.20 | 93.25 |
| 22 | 17/0.16 | 0.76 | 2.35 | 55.00 | |
|
20 |
26/0.16 |
0.94 | 2.55 | 34.60 | |
| 18 | 41/0.16 | 1.18 | 3.78 | 21.80 | |
| 16 | 26/0.254 | 1.49 | 3.10 | 14.64 | |
| 14 | 41/0.254 | 1.88 | 3.50 | 9.25 | |
| 12 | 65/0.254 | 2.36 | 4.00 | 5.82 | |
| 10 | 105/0.254 | 3.00 | 4.60 | 3.66 | |
| 9 | 131/0.254 | 3.70 | 5.30 | 2.96 | |
| 8 | 168/0.254 | 4.20 | 6.50 | 2.35 | |
| 7 | 210/0.254 | 4.70 | 7.00 | 1.87 | |
| 6 | 266/0.254 | 5.30 | 8.40 | 1.48 | |
| 5 | 329/0.254 | 5.80 | 9.00 | 1.17 | |
| 4 | 420/0.254 | 6.60 | 9.70 | 0.928 | |
| 3 | 532/0.254 | 7.50 | 10.50 | 0.744 | |
| 2 | 665/0.254 | 8.40 | 11.50 | 0.590 | |
| 1 | 836/0.254 | 9.40 | 13.50 | 0.467 | |
|
1/0 |
1045/0.254 | 10.50 | 14.60 | 0.370 | |
|
2/0 |
1330/0.254 | 11.90 | 16.00 | 0.297 | |
| 3/0 | 1672/0.254 | 13.00 | 17.50 | 0.236 | |
| 4/0 | 2109/0.254 | 14.70 | 19.10 | 0.187 |
