Anti-termite and rodent TüV PV1-F 4mm2 Solar Cable
The PV1-F solar cable is made of three-layer insulation structure of irradiation cross-linked polyolefin, nylon and irradiation cross-linked polyolefin, which is resistant to termite and rodents. In photovoltaic power generation systems, it can be used outdoors under sunlight or directly buried in the ground.
Product Information:
| Conductor | Cross-sectional Area | 4mm2 |
| Material | Stranded Tinned Copper | |
| Conductor Size (mm) |
52/(0.30±0.008) |
|
| Stranded OD. (mm) | 2.46 | |
| Inner Layer | Material | XLPO |
| Min Thickness (mm) | 0.50 | |
| OD. (mm) |
3.55±0.10 |
|
| Color | Black & Red | |
| Cover Layer | Material | Nylon |
| Min Thickness (mm) | 0.20 | |
| OD. (mm) |
4.15±0.10 |
|
| Color | Black | |
| Out Layer | Material | XLPO |
| Min Thickness (mm) | 0.50 | |
| OD. (mm) |
4.60±0.15 |
|
| Color | Black |
Advantages:
(1)Electron-beam cross-linked compounds.
(2)UV, ozone and hydrolysis resistant.
(3)High temperature resistant, the materials do not melt or flow.
(4)Good cold flexibility.
(5)Very long service life > 25 years at 90°C.
(6)Compatible to all popular connectors.
(7)Anti-termite / anti-rodent protection.
Packing & Delivery:
Application Scenario:
Global Exhibitions:
Company Profile:
SUNKEAN is a fast-growing solar company ,as well as a turnkey solution provider in China. Products cover PV modules,house solar power system, PV1-F Solar Cable , PV connectors, fence, photovoltaic inverter etc solar products .SUNKEAN is committed to providing the best solutions for users, installers, investors and all stakeholders. We always take the responsibility on customer’s demands. We make our effort for innovations and breakthroughs.
FAQ
Q: How could i get the sample ?
A: We have different kinds of XLPE insulation pv solar cable,photovoltaic cable,xlpe solar cable in stock, you can require for samples to check our quality.Samples are free provided, you only need to pay the courier fees.
Q: How long is the delivery time?
A1)For Sample: 1-3 Days;
A2)For small Orders: 3-10 Days;
A3)For mass Orders:15-20 Days;
Q: What is your terms of payment ?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance ,balance before shippment or against B/L.
If you are an end users , we can offer more detail information to you.Please, if you have any questions or concerns about shipping time and delivery, you can ask our professional products consultant.
