Low Voltage cable Single Core H07Z-K cable Insulated Flexible Installation Industrial Power Wires
SUNKEAN H07Z-K cable conductor uses stranded 1.5~120mm2 tin-plated or bare copper, PVC insulated, and meet RoHS requirements. Uniform insulation thickness ensures easy peeling and cutting.
PVC material Grounding Cable H07Z-K Information:
Stranded ,tinned or bare copper conductor 1.5~120mm2
Conductor
Insulation
PVC,RoHS compliant
Rated voltage
450/750V
Rated temperature
90°C
| Cable Name |
Cross Section (mm2) |
Construction (No./mm) |
Conductor O.D. (mm) |
Insulation O.D. (mm) |
Conductor Resistance Max (?/km) |
Dielectric Strength (VAC,5min) |
| H07Z-K | 1.5 | 30/0.25 | 1.58 | 3.10 | 13.7 | 2500 |
| 2.5 | 49/0.25 | 2.02 | 3.75 | 8.21 | ||
| 4 | 56/0.30 | 2.60 | 4.30 | 5.09 | ||
| 6 | 84/0.30 | 3.42 | 5.20 | 3.39 | ||
| 10 | 84/0.40 | 4.56 | 6.70 | 1.95 | ||
| 16 | 126/0.40 | 5.60 | 7.80 | 1.24 | ||
| 25 | 196/0.40 | 6.95 | 9.60 | 0.795 | ||
| 35 | 276/0.40 | 8.74 | 11.30 | 0.565 | ||
| 50 | 396/0.40 | 10.46 | 13.60 | 0.393 | ||
| 70 | 360/0.50 | 12.50 | 15.60 | 0.277 | ||
| 95 | 475/0.50 | 13.73 | 17.30 | 0.210 | ||
| 120 | 608/0.50 | 15.50 | 19.10 | 0.164 |
Packing:
Global Exhibitions:
Company Profile:
SUNKEAN is a fast-growing solar company ,as well as a turnkey solution provider in China. Products cover PV modules, solar cables, half cut cell solar panel , solar pv mounting structure, fence, Mini inverter for home etc solar products .SUNKEAN is committed to providing the best solutions for users, installers, investors and all stakeholders. We always take the responsibility on customer’s demands. We make our effort for innovations and breakthroughs.
If you are an end users , we can offer more detail information to you.Please, if you have any questions or concerns about shipping time and delivery, you can ask our professional products consultant.
