NYY-J Solar Cable 1 Core 50mm2 Direct Burial Wire
Power and control cable for ?xed installation in the following applications: direct burial and building installation, ?xed installation with various applications.
Product Description:
|
Conductor: |
Bare copper wire |
|
Core Insulation: |
PVC（*Filling compound over the core assembly） |
| Outer sheath: | PVC |
| Conductor stranding: | Single or multi-wire |
| Minimum bending radius: |
Single-core: 15 x outer diameter
Multi-core: 12 x outer diameter
|
| Nominal voltage: | U0/U: 0.6/1.0 kV |
|
Test voltage： |
4000V |
|
Protective conductor: |
J = with GN-YE protective conductor |
|
Temperature range: |
During installation: -5°C to +50°C Fixed installation: -40°C to +70°C |
|
Number of cores and mm2 per conductor |
Outer diameter (mm) |
Copper index (kg/km) |
Weight (kg/km) |
| 1x25 | 13 | 240 | 380 |
|
1x35 |
14 | 336 | 447 |
|
1x50 |
15 | 480 | 650 |
|
1x70 |
17 | 672 | 864 |
|
4x25 |
27 | 960 | 1620 |
|
5x25 |
29.9 | 1200 | 1920 |
Packing & Delivery:
Application Scenario:
Global Exhibitions:
Company Profile:
SUNKEAN is a fast-growing solar company, as well as a turnkey solution provider in China. Products cover panel solar systems, solar cables, solar extension cables, home energy solar systems, Solar power fences, three phase inverters etc solar products.SUNKEAN is committed to providing the best solutions for users, installers, investors, and all stakeholders. We always take responsibility for customers’ demands. We make our effort for innovations and breakthroughs.
FAQ
Q: How could I get the sample?
A: We have different kinds of XLPE insulation pv solar cable, photovoltaic cable, and xlpe solar cable in stock, you can require samples to check our quality. Samples are free provided, you only need to pay the courier fees.
Q: How long is the delivery time?
A1)For Sample: 1-3 Days;
A2)For small Orders: 3-10 Days;
A3)For mass Orders:15-20 Days;
Q: What are your terms of payment?
A: Payment<=1000USD, 100% in advance. Payment>=1000USD, 30% T/T in advance,balance before shipment or against B/L.
If you are an end user, we can offer more detailed information to you. Please, if you have any questions or concerns about shipping time and delivery, you can ask our professional products consultant.
